| 65UH5N-E |
| UHD Signage Display |
| |
| |
|
|
| |
| Tech Spec |
| |
| Panel |
| |
- Screen Size: 65"
-
Panel Technology: IPS -
Back Light Type: Edge -
Aspect Ratio: 16:9 -
Native Resolution: 3,840 X 2,160 (UHD) -
Refresh Rate: 60 Hz -
Brightness (Typ.): 500 nit -
Contrast Ratio: 1,100 : 1 -
Dynamic CR: 1,000,000 : 1 -
Color gamut: BT709 95% -
Viewing Angle (H x V): 178 × 178 -
Color Depth: 1.07 Billon Colors (10 bit (D)) -
Response Time: Tr : 8ms / Tf :10ms -
Surface Treatment (Haze): 28% -
Life Time (Min.): 50,000 Hrs -
Operation Hours (Hours / Days): 24 / 7 -
Portrait / Landscape: Yes / Yes
. |
| |
| |
| Mechanical Specification |
| |
- Bezel Color: Black
-
Bezel Width: 8.9 mm (T/R/L), 12.9 mm (B) -
Weight (Head): 24.2 kg -
Packed Weight: 30.4 kg -
Monitor Dimensions (W × H × D): 1,450.3 x 830.3 x 29.7mm (Without IR) -
Carton Dimensions (W × H × D): 1,600 x 970 x 172mm -
Handle: No -
VESA™ Standard Mount Interface: 300 × 300 mm
. |
| |
| |
| Key Feature |
| |
- Internal Memory 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor (External IR), Acceleration (Gyro) Sensor), Local Key Operation, Built-in Speaker, webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Cisco Certi, Crestron Connected®), Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom
. |
| |
| |
| Environment Conditions |
| |
- Operation Temperature: 0 °C to 40 °C
-
Operation Humidity: 10 % to 80 %
. |
| |
| |
| Power |
| |
- Power Supply: AC 100-240 V ~, 50/60 Hz
-
Power Type: Built-In Power
. |
| |
| |
| Power Consumption |
| |
- Typ./Max.: 145W / 200W
-
Smart Energy Saving (70%): 101.5W -
DPM: 0.5W -
Power off: 0.5W -
BTU (British Thermal Unit): 495 BTU/Hr(Typ.), 682 BTU/Hr(Max)
. |
| |
| |
| Certification |
| |
- Safety: CB / NRTL
-
EMC: FCC Class “B" / CE / KC -
ePEAT (US Only): Yes -
ErP / Energy Star: Yes (NewErP) / Yes -
ISTA6: Yes (~Sep. 23y, US Suffix Only) -
Carbon Trust: Yes (CO2 Reducing (TBD))
. |
| |
| |
| OPS Compatibility |
| |
- OPS Type Compatible: No
-
OPS Power Built In: No
. |
| |
| |
| Software Compatibility |
| |
- SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG ConnectedCare
. |
| |
| |
| Connectivity |
| |
- Input: HDMI In (3, 3,840 × 2,160 @ 60Hz, HDCP 2.2/1.4), DP In (3,840 × 2,160 @ 60Hz, HDCP 2.2/1.3), RS-232C In (4 Pin Phone-jack), RJ45 (LAN) In, IR In, USB In 2.0 (Type A)
-
Output: HDMI Out (3,840 × 2,160 @ 30Hz, Input (HDMI1/2/3/DP)), Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP / Output HDMI)
. |
| |
| |
| Language |
| |
- English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic
. |
| |
| |
| Accessory |
| |
- Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder(2EA), AC Cord Holder (1EA)
-
Optional: Slim Wall Mount (WB21LMA/B), Wall Mount (OLW480A/B) Wall Mount Adapter (AM-B330S)
. |
| |
| |
| Special Feature |
| |
- Tilt (Facedown): Yes (Max 30º degree, 40ºC temperature)
. |
| |
